Key Features of Upgraded Android Scanner
- [Upgraded] High-speed processing performance: Leading technology, based on Android 9.0 deep development, support multi-tasking process smoothly and ensure efficient work.
- Strong Recognition Ability: Famous 2D Scanner, help your inventory management with exceptional accuracy and efficiency.
- Diverse transmission functions: Support 4G/3G/ dual-band Wi-Fi/ Bluetooth, signal stability which does not easily lose connectivity.
- Designed for harsh working environments: compliant with IP66 enterprise-grade protection, it can be dust-proof, splash-proof, and the body can withstand 1.5m of drop impact. (with a wrist strap for safe operation to prevent the device from accidentally falling)
Product parameters
- OS: Android 9.0
- CPU: Cortex-A53 Quad-core 64-bit 2.0GHz
- RAM+ROM: 2GB+16GB
- Expand memory: Micro SD(TF) Supports up to 128GB
MUNBYN Scanner will make your work more advanced and efficient.
Data collection
Barcode scanning
- 2D scanner: N6601
- 2D Symbologies: PDF417,Micro PDF417,GS1 Composite,Aztec Code,Data Matrix,QR Code,Micro QR Code, MaxiCode,Hanxin Code, etc.
Camera
- Rear camera: 8MP HD camera,Support auto focus,
- Flash, Anti-shake, Macro shooting
Data communication
- WLAN: Dual-band 2.4GHz / 5GHz, Supporting IEEE 802 a/b/g/n/ac protocol
- WWAN:
2G: GSM（850/900/1800/1900MHz
3G：WCDMA（850/900/1900/2100MHz）
4G：FDD:B1/B3/B4/B7/B8/B12/B20
TDD:B38/B39/B40/B41
- Bluetooth: Support Bluetooth 2.1+EDR/3.0+HS/4.1+HS
- Transmission distance 5-10 meters
- GPS: Support GPS, Galileo, Glonass, Beidou
Battery capacity
Rechargeable polymer battery
- Capacity: 3.7V 4200mAh
- Standby time: >350 hours
- Working time: > 12 hours
- Charging time: ＜4H, using standard power adapter and data cable
Physical parameter
- Display: 4.5 inch IPS color display with resolution 480*854
- Expansion Card slot: PSAM x 2, Micro SIM card x 1 , TF card × 1
- Communication interface: Type-C USB x 1, OTG,POGO Pin x 1
User environment
- Protection level: IP66 (Water proof &Dust proof)
- Rolling test: 500×0.5m rolling for 6 sides
- Drop specification: 6 sides Supports 1.5 meters drops and 30 times to the concrete within the operating temperature
- Operating temperature: -20℃ - 55℃
- Storage temperature: -40℃ - 70℃
- Environment humidity: 5%RH--95%RH(no condensation)
